1. Cast Iron - Three Piece Design Ball Valves

• 1. Body, Side Piece: Cast Iron IS 210 GR FG 200
• 2. Stem: Stainless Steel 304 /316
• 3. Ball: Stainless Steel 304 / 316
• 4. Body Seat, Stem Seal: PTFE
• 5. Lever: MS with PVC Sleeve
• 6. Ends: Screwed up to 50 mm NB, 50 mm and above Flanged
• 7. Rating: PN 1.0 / PN 1.6
• 8. Design : BS 5351 /  IS/ISO 17292
• 9. Range: 15 mm to 200 mm NB

2. Forged and Stainless - Three Piece Design Ball Valves

• 1. Body, Side Piece: ASTM A 105, CF 8, CF 8M
• 2. Stem: Stainless Steel 304 / 316 / 410
• 3. Ball: Stainless Steel 304 / 316
• 4. Body Seat, Stem Seal: PTFE
• 5. Lever: MS OR SS with PVC Sleeve
• 6. Ends: Socket Weld / Screwed / Flanged
• 7. Design / Testing: BS 5351 / IS/ISO 17292
• 8. Rating: 800# / 1500# / 2500#
• 9. Range: 15 mm to 50 mm NB

3. Cast Steel and Stainless Steel - Three Piece Design Ball Valve

• 1. Body, Side Piece: ASTM A 216 GR WCB, CF 8, CF 8M
• 2. Stem: Stainless Steel 304 / 316 / 410
• 3. Ball: Stainless Steel 304 / 316
• 4. Body Seat, Stem Seal: PTFE
• 5. Lever: MS OR SS with PVC Sleeve
• 6. Ends: Socket Weld / Flanged
• 7. Design / Testing: BS 5351 / IS/ISO 17292
• 8. Rating: 150# / 300# / 600# / 900#
• 9. Range: 15 mm to 250 mm NB
• Note: Trunnion mounted, 2 port, 3 port valves available
